Key Features

  • icon
    Engine (CC) 2235 CC
  • icon
    Clutch Type Single
  • icon
    Gear Type
  • icon
    Drive Type 2WD

Model Overview

The John Deere 5036 D tractor offers a variety of features designed to meet the demands of farmers. It is equipped with a coolant cooling system and a dry-type dual-element air filter. The tractor has a single clutch, 8 forward plus 4 reverse gears, and utilizes Collarshift transmission technology. It operates at speeds ranging from 3.13 to 34.18 KMPH in forward motion and 4.10 to 14.84 KMPH in reverse. The tractor also features Oil Immersed Disc Brakes for efficient traction, a heavy hydraulic lifting capacity of 1600 KG with automatic depth and draft control linkage points, power steering for easy maneuvering, and a large 60-liter fuel-saving tank for extended working hours. Additionally, it is a 2WD tractor weighing 1760 KG, with a wheelbase of 1970 MM, ground clearance of 390 MM, and a turning radius of 2900 MM. It runs on 6.00x16 meter front tires and 12.4x28 meter rear tires. Furthermore, it is designed with advanced safety and convenience features such as a monitoring & tracking system, rollover protection system, adjustable front axle, and more. The tractor is also compatible with various accessories like a bumper, canopy, ballast weights, and tow hook, ensuring its versatility and utility on the field.

Engine

  • Air Filter Dry Type
  • Max Torque 140 Nm
  • No of Cylinder 3
  • Drive type 2 WD
  • Cooling System Forced circulation of coolant
  • PTO HP 30.82
  • Engine Rated RPM 2200 RPM
  • Horse Power (HP) 36 HP
  • Engine Capacity 2235 CC
  • Engine Type Di Engine

Transmission

  • Reverse Speed (Min-Max) 3.89 ? 11.84 Kmph
  • Forward Speed (Min-Max) 23.0 Kmph
  • Brake Type Oil immersed Brakes
  • Clutch type Single diaphragm clutch
  • Gear Box 8 Forward + 2 Reverse
  • Transmission Type Partial Constant Mesh

Specification

  • Fuel Tank Capacity 50 litre

Dimension and weight

  • Ground Clearance 370 mm
  • Tractor width 1735 MM
  • Overall Length 3390 MM
  • Wheelbase 1880 MM
  • Weight 1805 KG

Tyre size

  • Rear 12.4 X 28 / 13.6 X 28
  • Front 6.00 X 16

Hydraulics

  • Linkage & Controls 3 Point Linkage
  • Lifting capacity (in kg) 1500 kg

Assurance

  • Warranty 2 Years

Others

  • Electricals 12V, 80 Ah Battery
  • Accessories Tool Kit, Rear Tow Hook, Linkage Drawbar, Front tow Hook
  • Steering Type Mechanical/Power

Similar Tractors

Reviews

Trakstar 536 2WD Tractor User Reviews

0 / 5
Based on 0 User Reviews
  • Fuel Consumption
    0
  • Design
    0
  • Maintenance Cost
    0
  • Multitasking
    0
  • star
  • star
  • star
  • star
  • star

Write a Review

Trakstar 536 2WD Tractor

Rate Below Performance Parameter

Fuel Consumption
Maintenance Cost
Design
Multitasking

Popular TRAKSTAR GROWMAX Tractors

View All

New Tractors in 31-40 HP

View All

Specifications Of Trakstar 536 2WD Tractor

  • Air Filter Dry Type
  • Max Torque 140 Nm
  • No of Cylinder 3
  • Drive type 2 WD
  • Cooling System Forced circulation of coolant
  • PTO HP 30.82
  • Engine Rated RPM 2200 RPM
  • Horse Power (HP) 36 HP
  • Engine Capacity 2235 CC
  • Engine Type Di Engine

Specifications Of Trakstar 536 2WD Tractor

  • Reverse Speed (Min-Max) 3.89 ? 11.84 Kmph
  • Forward Speed (Min-Max) 23.0 Kmph
  • Brake Type Oil immersed Brakes
  • Clutch type Single diaphragm clutch
  • Gear Box 8 Forward + 2 Reverse
  • Transmission Type Partial Constant Mesh

Specifications Of Trakstar 536 2WD Tractor

  • Fuel Tank Capacity 50 litre

Specifications Of Trakstar 536 2WD Tractor

  • Ground Clearance 370 mm
  • Tractor width 1735 MM
  • Overall Length 3390 MM
  • Wheelbase 1880 MM
  • Weight 1805 KG

Specifications Of Trakstar 536 2WD Tractor

  • Rear 12.4 X 28 / 13.6 X 28
  • Front 6.00 X 16

Specifications Of Trakstar 536 2WD Tractor

  • Linkage & Controls 3 Point Linkage
  • Lifting capacity (in kg) 1500 kg

Specifications Of Trakstar 536 2WD Tractor

  • Warranty 2 Years

Specifications Of Trakstar 536 2WD Tractor

  • Electricals 12V, 80 Ah Battery
  • Accessories Tool Kit, Rear Tow Hook, Linkage Drawbar, Front tow Hook
  • Steering Type Mechanical/Power
